6Ton Diesel Forklift Truck LG60D(T) III Engine 85kw Fork Lifter Euro III
Features of 6Ton Diesel Forklift Truck LG60DT(III) Engine 85kw Fork Lifter Euro III
1. Adopt international leading ergonomics and CAE technology, increase the operating space, the driver is more comfortable, effectively improve the operating efficiency and safety;
2. The hood opening angle is increased to 80°, which makes maintenance more convenient; the hood lock is light and flexible to open, and the gas spring self-locking function ensures the safety of maintenance;
3. The vehicle is equipped with a standard intelligent shift system to prevent the start of the second gear, improve the life of the gearbox, and greatly reduce the labor intensity of the cab;
5. The hydraulic system adopts load sensing technology (steering priority), small diameter steering wheel, reduces oil temperature by 10%, and saves fuel by 5%;
6. Adopting Xichai 4.75L electronically controlled supercharged and intercooled diesel engine, the idling state can meet the requirements of forklift operation and meet the latest national environmental protection requirements;
7. All electrical components are centrally arranged in the control box, the wiring harness is neat and beautiful, to prevent the entry of dust and rain, and improve the reliability of the ECU;
8. The standard power supply cut-off device is standard, which enhances the safety of the electrical system. The protective lamp holder prevents the work lamp from being damaged by slight cargo;
9. The visual field of the portal is widened, the strength and rigidity of the portal is improved, and the impact resistance is enhanced;
10. Adopt high-level air intake method to effectively reduce the engine air intake resistance and dust intrusion, and the exhaust pipe is flanged to prevent air leakage;
11. Humanized design such as lengthening of engine oil dipstick, advance of diesel filter and opening of water tank cover plate make daily maintenance more convenient;
12. Oil-water separation parallel radiator can meet the power requirements of high strength and high load working conditions;
13. Adopt dynamic braking system to make braking more agile and reliable (matching special brake valve for glass working conditions);
14. Optimized body design greatly increases the maintenance space of the vehicle.
Technical parameters of 6Ton Diesel Forklift Truck LG60DT Engine 85kw Fork Lifter Euro III
| model | Unit | LG60(T)III |
| Power form | | Diesel |
| Rated load | kg | 6000 |
| J Load center distance | mm | 600 |
| h1 Maximum lifting height | mm | 3000 |
| h3 Free lifting height | mm | 200 |
| L5×W×T fork size | mm | 65×1220×150 |
| Mast angle | deg | F:7 R:12 |
| L3 front overhang | mm | 595 |
| L4 rear overhang | mm | 675 |
| Size | L1 Total length | mm | 4790 |
| W1 Total length | mm | 1995 |
| h2 Master non-lift height | mm | 2500 |
| h4 Safety frame height | mm | 2450 |
| Block shelf (fork rack) height | mm | 1380 |
| R1 Minimum turning radius | mm | 3300 |
| Ra minimum right angle stacking channel | mm | 3260 |
| width |
| Maximum speed | Km/h | 24/29 |
| (Full load/empty load) |
| Lifting speed | mm/s | 510/530 |
| (No load/full load) |
| Maximum grade | % | 35/20 |
| (Full load/empty load) |
| Self weight | kg | 8950 |
| Tire | Front wheel | | 8.25-15-14PR |
| Rear wheel | | 8.25-15-14PR |
| Track | S front wheel | mm | 1470 |
| P Rear wheel | mm | 1700 |
| L2 wheelbase | mm | 2300 |
| Min. ground clearance | m2 door frame | mm | 200 |
| m1 frame | mm | 250 |
| Diesel fuel tank | ltr | 160 |
| Euro III engine |
| Model | | XICHAI/CA4DF3-12GCG3U(Euro III) |
| rated power | kW/r | 85/2200 |
| Rated torque | N·m/r | 460/1400-1500 |
| Number of cylinders | | 4 |
| Displacement | L | 4.75 |
Our advantages:
1) Original parts and good working condition;
2) Low working hours and high working efficiency;
3) Strong working power and stability;
4) Complete accessory and no oil leaking;
5) Competitive price and good skills;
6) Good After-sales Service
FAQ:
1. How to guarantee the condition and lifetime of the machine ?
A: All our exported machine are New and Original brand, pass pre-delivery quality testing!
We are responsible for our trucks and machine quality.
2. How to have after sale service from us ?
A: We have old suppliers in China, original new parts are available for us to get, with reasonable price and in short time.
3. How can customers make visit and checking in China ?
A: We arrange everything ready for your journey in China, welcome your happy visit.
