XCMG Road Construction Road Roller Operating Weight 16t Single Drum Compact Vibratory Road Roller XS163J
Highlights of XCMG Road Construction Road Roller Operating Weight 16t Single Drum Compact Vibratory Road Roller XS163J
Comfortable driving
The spacious and bright cab has wide, comfortable and comfortable vision.
Easy operation
User-friendly design dashboard layout is reasonable, the operation buttons--clear.
The use of a car box with a synchronized shifter saves effort in operation.
The hydraulic system is reliable and durable
Imported open gear pump is standard, with long service life, stable vibration start and stop, and high compaction quality.
Energy saving and environmental protection power
Shangchai water-cooled engine, ultra-low noise, in line with China II emission standards. The maintenance-free battery can be easily started at low temperature and works freely.
Optional
Optional integral cam wheels, split cam wheels, air-conditioned cab.
Efficient and reliable vibration compaction system
Unique cylindrical structure, good rigidity, high strength, short cylindrical bearings are used for bearings, high limit speed, strong bearing capacity, left and right vibration chamber
Symmetrically arranged to avoid the polarization phenomenon of the vibration wheel.
The vibration bearing can be lubricated when the roller is running. The lubrication method is simple and convenient, and the failure rate of the lubrication system is extremely low.
CNC cutting and blanking, CNC coiling, CNC bending machine, and CNC horizontal machining center are used to ensure the manufacturing accuracy of the overall processing.
Technical specification of XCMG Road Construction Road Roller Operating Weight 16t Single Drum Compact Vibratory Road Roller XS163J
| Item | XS163J |
| Working weight | 16000kg |
| Front wheel distribution weight | 7700kg |
| Static pressure | 362Mpa |
| Speed range | F/R |
| Speed Ⅰ | 2.85/2.88km/h |
| Speed Ⅱ | 5.08/5.02km/h |
| Ⅲ speed | 11.17km/h |
| Theoretical gradeability | 30% |
| Minimum turning radius | 6500mm |
| Steering angle | 33 |
| Swing angle | 土11 |
| Vibration frequency | 28Hz |
| Nominal amplitude (high/low) | 1.9/0.95 |
| Exciting force @high/low amplitude | 290/145KN |
| Engine model | Shangchai SC4H140.192 |
| Rated power@1800r/min | 103Kw |
| Engine fuel consumption | 205L@ 100km/h |
| Hydraulic oil tank volume | 170L |
| Fuel tank volume | 310L |
Packing & Delivery:
Nude package.
This model truck crane shipped by roro or bulk ship.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal and use the machine.
* Engineers available to service machinery overseas.
